1600W Heating Elements

Selecting the right heating element involves matching wattage, wavelength, voltage, and physical dimensions to your process. Short-wave infrared suits fast-response, high-watt-density applications like automotive curing, while medium-wave is preferred for ink drying and plastics. Fannon Products' technical team can assess your process parameters and recommend the correct lamp specification, reflector type, and configuration.

Fannon Products manufactures infrared heating elements from 250W to 6000W and beyond, including 1600W configurations. Lamps can be custom-specified in virtually any wattage, length, and voltage combination to match your exact process heating requirements, whether for replacement or new system builds.

Fannon's infrared heating elements are available in a wide range of voltages including 115V, 120V, 208V, 230V, 240V, 277V, 400V, 415V, 480V, 575V, and 600V. This flexibility ensures compatibility with industrial power supplies across North America and international facilities.

Fannon's infrared heating elements are rated for 5,000+ hours of operation. This long service life, combined with competitive pricing and lamps typically held in stock for fast 1–2 day shipping, minimizes downtime and total cost of ownership for industrial operations.

Fannon offers three reflector options: 24K gold integral reflectors that save 23.5% energy versus standard lamps by directing infrared precisely at the workpiece, high-temperature white oxide reflectors, and clear quartz with no reflector for open-fixture installations. The Goldenrod lamp line features the integral gold reflector for maximum directional efficiency.

Yes. Fannon Products specializes in custom infrared lamp manufacturing. Elements can be produced in virtually any length under 40 inches, wattage, voltage, and wiring configuration — series or parallel — with or without integral reflectors. Custom orders are supported by direct technical consultation and are manufactured at their facility in Algonac, Michigan.
