UV Curable Clear Coat — Protective Finish

Yes, UV light is specifically designed to cure UV-formulated clear coats. UV LED curing systems emit concentrated light at wavelengths of 395–405nm, which activates photoinitiators within the clear coat formulation. This triggers rapid polymerization, hardening the coating in seconds. Fannon Products' UV LED systems deliver 16W/cm² power intensity for fast, consistent clear coat curing across automotive and industrial surfaces.

UV-curable clear coats are specially formulated coatings that, once cured by UV LED light, provide a protective barrier against UV degradation, scratches, and environmental damage. The cured film itself helps shield the underlying surface. Fannon Products' UV LED curing systems are compatible with a wide range of UV-formulated clear coat products used in automotive finishing, plastics coating, and industrial surface protection.

Fannon Products' UV LED curing systems operate at a wavelength range of 395–405nm. This range is effective for curing a broad spectrum of UV-formulated inks, coatings, and clear coats used in automotive, screen printing, inkjet printing, and industrial finishing applications. All three available models — 3-inch, 6-inch, and 9-inch — operate at this wavelength.

Fannon Products offers three UV LED curing system models. The 3-inch module (FP-120-80x40-395) runs on 120V at 540W. The 6-inch module (FP-120-160x40-395) operates on 120V at 1080W. The 9-inch module (FP-220-240x40-395) requires 220–230V at 1620W. All models deliver a consistent power intensity of 16W/cm² and use an air-cooled design for simplified installation.

All Fannon Products UV LED curing systems use an air-cooled design, eliminating the need for complex water-cooling infrastructure. This simplifies installation and reduces ongoing maintenance requirements. The air-cooled approach makes the systems particularly practical for retrofit installations and new production line setups in printing, automotive, and industrial environments where minimal downtime is critical.

Fannon Products' UV LED curing systems are suited for a wide range of industries including automotive (paint and clear coat curing), screen printing, inkjet printing, plastics finishing, and general commercial and industrial manufacturing. Their modular sizing — available in 3-inch, 6-inch, and 9-inch configurations — allows the systems to integrate into diverse production line setups across these sectors.
