2x1000W Infrared Paint Curing Lamps for Powder Coating

For powder coating, a non-contact infrared thermometer with an emissivity adjustment setting and a measurement range of at least 450°F (232°C) is recommended. Look for models with fast response times and narrow spot ratios for accurate surface readings. Pairing a quality infrared thermometer with Fannon's curing lamps ensures you can consistently verify that target cure temperatures are being reached across the part surface.

Most powder coatings cure at metal temperatures between 325°F and 400°F (163°C–204°C), depending on the specific powder formulation. Always consult your powder manufacturer's data sheet for exact cure temperature and dwell time requirements. Fannon Products' infrared lamps reach operating temperatures up to 4,000°F, delivering the radiant energy needed to bring workpieces to proper cure temperature quickly and uniformly.

Short-wave infrared provides instant thermal response and very high color temperatures (~4,100°F), making it ideal for fast cycle times and thin substrates. Medium-wave infrared heats more gradually and penetrates deeper into coatings, which can be beneficial for thicker powder coats or temperature-sensitive substrates. Fannon Products offers both wavelength options, and our technical team can help you select the best fit for your application.

Fannon Products' infrared lamps are rated for over 5,000 hours of service life with good resistance to thermal shock. Actual lamp life depends on operating conditions, duty cycle, and handling practices. With proper installation and care, our lamps deliver consistent, reliable performance for thousands of curing cycles, reducing downtime and replacement costs in production environments.

Yes. Fannon Products' infrared heating systems are designed for automotive primer coat, color coat, clear coat, and powder coat curing applications. The same short-wave or medium-wave lamp technology that cures powder coatings can also be configured for other paint stages, making these lamps versatile assets in automotive refinishing and manufacturing paint lines.

Yes. Fannon Products manufactures infrared lamps in virtually any length, wattage, and voltage configuration, including 115V, 120V, 208V, 230V, 240V, 277V, 400V, 480V, and more. Wattage ranges span from under 500W to over 10,000W. Custom reflector options including 24K gold, white oxide, and clear quartz are also available. Contact our team at 810-794-2000 to discuss your specific requirements.
